| Ref. | Part# | Qty. | Description | Price |
|---|
| 1 | 121030 | 1 | Water outlet from R.H. cyl. head | | | |
Part#: 121030 Qty: 1 |
| 2 | 121031 | 1 | Water outlet form L.H. cyl. head | | | |
Part#: 121031 Qty: 1 |
| 3 | 134952 | 2 | Gasket With Amianthus | $8.28 | | |
Part#: 134952 Qty: 2$8.28 |
| 3 | 134952 | 2 | Gasket - Without Amianthus | $8.28 | | |
Part#: 134952 Qty: 2$8.28 |
| 4 | 121122 | 1 | L.H. pipe | | | |
Part#: 121122 Qty: 1 |
| 5 | 121121 | 1 | R.H. pipe | | | |
Part#: 121121 Qty: 1 |
| 6 | 121471 | 1 | Manifold for water delivery to thermostat | | | |
Part#: 121471 Qty: 1 |
| 7 | 121166 | A | Sleeve | $27.50 | | |
Part#: 121166 Qty: A$27.50 |
| 8 | 12173890 | 8 | Clamp | $1.85 | | |
Part#: 12173890 Qty: 8$1.85 |
| 9 | 122938 | 1 | Sleeve | $74.77 | | |
Part#: 122938 Qty: 1$74.77 |
| 10 | 13000690 | 2 | Clamp | $2.50 | | |
Part#: 13000690 Qty: 2$2.50 |
| 11 | 10902424 | 2 | Screw | $1.00 | | |
Part#: 10902424 Qty: 2$1.00 |
| 12 | 12601271 | 2 | Washer | | | |
Part#: 12601271 Qty: 2 |
| 13 | 11499921 | 1 | Stud | | | |
Part#: 11499921 Qty: 1 |
| 14 | 10615474 | 1 | Washer | $0.23 | | |
Part#: 10615474 Qty: 1$0.23 |
| 15 | 15896211 | 1 | Nut | | | |
Part#: 15896211 Qty: 1 |
| 16 | 152875 | 1 | Heater water delivery pipe | | | |
Part#: 152875 Qty: 1 |
| 17 | 124961 | 1 | Sleeve | $49.92 | | |
Part#: 124961 Qty: 1$49.92 |
| 18 | 12179590 | 2 | Clamp | | | |
Part#: 12179590 Qty: 2 |
| 19 | 10450490 | 1 | Bracket | $2.45 | | |
Part#: 10450490 Qty: 1$2.45 |
| 20 | 124145 | 1 | Thermostat body | | | |
Part#: 124145 Qty: 1 |
| 21 | 109671 | 2 | Thermostat | | | |
Part#: 109671 Qty: 2 |
| 22 | 105192 | 2 | Gasket | $16.25 | | |
Part#: 105192 Qty: 2$16.25 |
| 23 | 13540921 | 4 | Stud | $0.48 | | |
Part#: 13540921 Qty: 4$0.48 |
| 24 | 12601279 | 4 | Washer | $0.07 | | |
Part#: 12601279 Qty: 4$0.07 |
| 25 | 15896211 | 4 | Nut | | | |
Part#: 15896211 Qty: 4 |
| 26 | 130282 | 1 | Drain plug After exhaustion use no. 130282 | $9.50 | | |
Part#: 130282 Qty: 1$9.50 |
| 27 | 10297760 | 1 | Gasket | $1.00 | | |
Part#: 10297760 Qty: 1$1.00 |
| 28 | 104628 | 1 | Thermistor | $142.44 | | |
Part#: 104628 Qty: 1$142.44 |
| 29 | 112030 | 1 | Union for reservoir breather | | | |
Part#: 112030 Qty: 1 |
| 30 | 134963 | 1 | Gasket - With Amianthus | $15.42 | | |
Part#: 134963 Qty: 1$15.42 |
| 30 | 134963 | 1 | Gasket - Without Amianthus | $15.42 | | |
Part#: 134963 Qty: 1$15.42 |
| 31 | 10903421 | 2 | Screw | | | |
Part#: 10903421 Qty: 2 |
| 32 | 11193279 | 2 | Washer | | | |
Part#: 11193279 Qty: 2 |
| 33 | 124144 | 1 | Thermostat body cover | | | |
Part#: 124144 Qty: 1 |
